BOTTOM LOADING ARMS
Models: GFG-LA-BL
GREENDECK™ Loading Arms, engineered by GREENFIELD GLOBAL LLC, deliver high-performance, precision-controlled loading and
unloading for a broad range of liquid products. Designed to meet the demanding requirements of terminals, fuel distribution centers,
chemical plants, and refineries, our arms are manufactured with a deep focus on safety, durability, and operational efficiency
BOTTOM LOADING ARM (GFG-LA-BL)
- Certified test report verifying specified settings and leakage performance
- “Air-cushion” pallet design for low leakage performance of no more than 1 SCFH at 90% of the set pressure
- Hinged Pallet Assembly can open approximately 75 degrees to provide full flow area as well as automatic resealing when tank pressure is decreased.
- Serialized unit and associated weights for easy identification and traceability
- Flow at fully open pressure marked on unit [OSHA 1910.106(b)(3)(v)]
KEY CHARACTERISTICS:
- Closed-loop vapor recovery system for emission control
- Operators remain on the ground—reducing fall risk
- Integrated quick-connect couplers and emergency
breakaway valves - Excellent resistance to electrostatic discharge and fluid
spillage - Swivel assemblies designed for high flow rates and long
service life
ADVANTAGES
- Smooth, efficient operation with minimal clearance required
- Reduced downtime through robust and simple mechanics
- Maximum access to multiple compartments
- Enhanced operator safety with advanced control options
- The GFG-LA-BL Bottom Loading Arm is designed for
safe, fast, and ergonomic fluid loading from the bottom
of tank trucks. Built with operator safety and emission
reduction in mind, it keeps all operations at ground
level—eliminating the need for personnel to climb onto
vehicles.
- Closed-loop vapor recovery system for emission control
- Operators remain on the ground—reducing fall risk
- Integrated quick-connect couplers and emergency
breakaway valves - Excellent resistance to electrostatic discharge and fluid
spillage - Swivel assemblies designed for high flow rates and long
service life
- Meets strict health, safety, and environmental standards
- Faster loading cycles with minimal spillage
- Low maintenance and long service life
- Compatible with high-turnover operations
